62
8-3.Inter
polation tim
e period
【
Interpolation
time
period
：
60C2h
】
is
set
automatically
accordin
g
to
the
communication
cycle, please do not change.
Communication period
60C2h-01h
60C2h-02h
250us
25
-5
500us
5
-4
1ms
1
-3
2ms
2
-3
4ms
4
-3
Index
Sub-Index
Name
Units
Access
60C2h
-
Interpolation time period
-
-
00h
Highest Sub-Index supported
-
RO
01h
Interpolation time period value
-
RW
02h
Interpolation time index
-
RW
9. Parameter list
9-1.CoE object
word
9-1-
1.
Communication Pr
ofile zone
Index
Name
Data type
Access
1000h
VAR
device type
UNSIGNED32
RO
1001h
VAR
error register
UNSIGNED8
RO
1600h~03h
RECORD
Receive PDO mapping
UNSIGNED32
RW
1A00h~03h
RECORD
Transmit PDO mapping
UNSIGNED32
RW
69
71
Table of Contents
Table of Contents
5
Confirmation When Receive the Products
9
Safety Caution
9
Servo System Model
11
1-1.Servo Driver
11
1-1-1.Part Description
11
Model Name
11
Performance
12
1-2.Servo Motor
13
1-2-1.Part Description
13
Model Name
14
Cable Configuration
14
Model Name
15
1-4.Other Accessories
16
1-4-1.Regenerative Resistor
16
Product Installation
17
2-1.Servo Drive Installation
17
2-1-1.Installation Location
17
2-1-2.Environment Conditions
18
2-1-3.Installation Standard
18
2-2.Servo Motor Installation
20
Installation Environment
20
Environment Conditions
21
2-2-3.Installation Notes
21
2-3.Servo Motor Dimension
25
2-4.Servo Drive Dimension
29
Servo Drive and Motor Wiring
31
Main Circuit Terminals
31
Control Terminals
32
Operation before Using Servo System
34
4-1.Operate Panel
34
4-1-1.Group P Parameters
35
4-1-2.Group U Parameters
36
FX-XX Auxiliary Function
40
Panel Key Operation
43
Change Motor Code
44
Gain Adjustment
45
5-1.Self-Adaption
45
Self-Adaption Mode Selection Switch Parameter
46
Recommended Inertia Ratio under Default Parameters
48
5-2.Auto-Tuning
49
No Instruction Auto-Tuning
49
Auto-Tuning with Instruction
49
5-3.Manual Adjustment
50
5-3-1.Manual Adjustment Steps
50
5-3-2.Manual Adjustment Parameter and Function
51
5-4.Vibration Suppression
52
Ethercat Communication Specification
55
Canopen Operation Mode
56
7-1.Homing Mode
56
7-1-1.Summary
56
7-1-2.Operation Steps
57
7-1-3.Related Object Table
57
7-2.Cyclic Synchronous Position Mode
58
7-2-1.Summary
58
7-2-2.CSP Mode
58
7-2-3.Operation Steps
58
7-2-4.Related Object Table
59
7-3.Cyclic Synchronous Velocity Mode
60
7-3-1.Summary
60
7-3-2.The Function of CSV Mode
61
7-3-3.Operation Steps
61
7-3-4.Related Object Table
62
7-4.Cyclic Synchronous Torque Mode
62
7-4-1.Summary
62
7-4-2.The Function of CST Mode
63
7-4-3.Operation Steps
63
7-4-4.Related Object Table
64
Mode Common Function
65
8-1.Touch Probe Function
65
8-1-1.Summary
65
8-1-2.Operation Steps
65
8-1-3.Related Object Table
65
8-2.Position Information
68
8-2-1.Electronic Gear Function
68
Initialization of Absolute Encoder
69
8-2-3.Position Range Limit
69
8-3.Interpolation Time Period
70
Parameter List
70
9-1.Coe Object Word
70
9-1-1.Communication Profile Zone
70
9-1-2.Driver Profile Zone
71
9-2.Driver Parameters
74
9-2-1.Group P Parameters
74
9-2-2.Group F Parameters
93
9-2-3.Group U Parameters
93
Appendix
98
Appendix 1 Motor Specification Table
98
Appendix 2. List of Servo Drive and Motor Matching
100
Appendix 3. Alarm List
102
Appendix 4. Modbus Address List
113
