91
Rated output power
[W]
100
200
200
400
Protection level
IP65
Motor insulation
level
Class F
（
155
℃
）
Ambient
temperature
－
15
℃
～＋
40
℃
Ambient humidity
Relative humidity < 90% (no condensation)
Voltage level
220V
Motor model
MS
5H
-60ST
5S-80ST
5H
-80ST
CS01330
CS02430
CS02430
-20P4-S01/S02
-20P7-S01/S02
-20P7-S01/S02
Motor code
(no brake/with
brake
）
50C4/58C4
5011/5811
50D1/58D1
Encoder bit
numbers
17
17
17
Polar logarithm
5
5
5
Rated speed [rpm]
3000
3000
3000
Max speed [rpm]
650
0
5200
5200
Rated torque [Nm]
1.27
2.39
2.39
Max torque [Nm]
4.45
7.17
7.17
Overload multiples
3.5
3
3
Rated current [mA]
2800
4000
4000
Max current [mA]
9800
12000
12000
Phase resistor
[mΩ]
1665
990
990
98
100
