Xinje DS5E Series User Manual

138
width
P2-77
Third notch
frequency
Hz
5000
50~5000
√
1|2|3|4|5|6|7|10
6.7
P2-78
Third notch
attenuation
0.1dB
70
50~1000
√
1|2|3|4|5|6|7|10
6.7
P2-79
Third notch band
width
Hz
0
0~1000
√
1|2|3|4|5|6|7|10
6.7
P2-80
Fourth notch
frequency
Hz
5000
50~5000
√
1|2|3|4|5|6|7|10
6.7
P2-81
Fourth notch
attenuation
0.1dB
70
50~1000
√
1|2|3|4|5|6|7|10
6.7
P2-82
Fourth notch band
width
Hz
0
0~1000
√
1|2|3|4|5|6|7|10
6.7
P2-83
Fifth notch frequency
Hz
5000
50~5000
√
1|2|3|4|5|6|7|10
6.7
P2-84
Fifth notch
attenuation
0.1dB
70
50~1000
√
1|2|3|4|5|6|7|10
6.7
P2-85
Fifth notch band
width
Hz
0
0~1000
√
1|2|3|4|5|6|7|10
6.7
P3-XX：
Parameter
Function
Unit
Default
value
Range
Effective
Suitable mode
Reference
chapter
P3-00
V-REF Function
Allocation
0-V-REF as Speed
Instruction Input
1-V-REF will be used
as input reference
value of external
speed limit. The actual
speed limit depends on
the speed limit of
external analog
quantity.
2-Speed Feedforward
-
0
0~2
○
1|2|4
5.5
P3-01
Analog voltage
corresponding to rated
speed (5E/5L not
support)
0.001V
10000
1500~30000
○
1|2|4
5.5
P3-02
Analog voltage speed
filter (5E/5L not
support)
0.01ms
0
0~10000
√
1|2|4
5.5
P3-03
Speed instruction
input dead zone
voltage (5E/5L not
support)
0.001v
0
0~500
√
1|2|4
5.5
P3-04
V-REF analog speed
direction(5E/5L not
-
0
0~1
√
1|2|4
5.5
