Xinje XC3 Series User Manual

Appendix 1 special soft device list
absolute、relative bit:
sending”
M8178 Direction flag
1 is positive direction, the correspond
direction port is on
M8179 PULSE_4 “sending pulse” flag Being ON when sending the pulse,
M8180
overflow flag of “32 bits pulse
sending”
When overflow, Flag is on
M8181 Direction flag
1 is positive direction, the correspond
direction port is on
ID function specification
M8190 C600 (24 segments) 1 is absolute, 0 is relative
M8191 C602 (24 segments) 1 is absolute, 0 is relative
M8192 C604 (24 segments) 1 is absolute, 0 is relative
M8193 C606 (24 segments) 1 is absolute, 0 is relative
M8194 C608 (24 segments) 1 is absolute, 0 is relative
M8195 C610 (24 segments) ……
M8196 C612 (24 segments)
M8197 C614 (24 segments)
M8198 C616 (24 segments)
M8199 C618 (24 segments)
M8200 C620 (24 segments)
M8201 C622 (24 segments)
M8202 C624 (24 segments)
M8203 C626 (24 segments)
M8204 C628 (24 segments)
M8205 C630 (24 segments)
M8206 C632 (24 segments)
M8207 C634 (24 segments)
M8208 C636 (24 segments)
M8209 C638 (24 segments)
M8210
Pulse alarm flag (frequency change
suddenly) 1 is alarm, 0 is correct PULSE_1
M8211 Neglect the alarm or not When flag is 1, stop sending alarm PULSE_1
M8212
Pulse alarm flag (frequency change
suddenly) 1 is alarm, 0 is correct PULSE_2
M8213 Neglect the alarm or not When flag is 1, stop sending alarm PULSE_2
M8214
Pulse alarm flag (frequency change
suddenly) 1 is alarm, 0 is correct PULSE_3
M8215 Neglect the alarm or not When flag is 1, stop sending alarm PULSE_3
M8216
Pulse alarm flag (frequency change
suddenly) 1 is alarm, 0 is correct PULSE_4

Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
