Xinje XC3 Series User Manual

Appendix 1 special soft device list
Positive/negative count
ID Counter ID Specification
M8270 24 segments HSC interruption loop (C600) if set it to be 1, then loop executing
the interruption; or else execute
only one time interruption;
M8271 24 segments HSC interruption loop (C602)
M8272 24 segments HSC interruption loop (C604)
M8273 24 segments HSC interruption loop (C606)
M8274 24 segments HSC interruption loop (C608)
M8275 24 segments HSC interruption loop (C610)
M8276 24 segments HSC interruption loop (C612)
M8277 24 segments HSC interruption loop (C614)
…… ……
M8279 24 segments HSC interruption loop (C618)
M8280 24 segments HSC interruption loop (C620) if set it to be 1, then loop executing
the interruption; or else execute
only one time interruption;
M8281 24 segments HSC interruption loop (C622)
…… ……
M8284 24 segments HSC interruption loop (C628)
M8285 24 segments HSC interruption loop (C630) if set it to be 1, then loop executing
the interruption; or else execute
only one time interruption;
…… ……
M8289 24 segments HSC interruption loop (C638)
M8217
Neglect the alarm or not When flag is 1, stop sending alarm PULSE_4
M8218
Pulse alarm flag (frequency change
suddenly) 1 is alarm, 0 is correct PULSE_5
M8219 Neglect the alarm or not When flag is 1, stop sending alarm PULSE_5
ID
Counter Nr.
Function Specification
M8238 C300~C498
Positive/negative counter
control
0 is increment counter, 1 is decrement
counter, default is 0
24 segments HSC interruption loop (M8270~M8289)

Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
