iFT Series Hardware Installation Manual ADPRO

18 27817_05

6. Connectharddisk2tothepowersupply,andtotheSATA2connectoronthemotherboardwiththeSATA

cable(#16520877).



Caution!

DonotbendtheSATAcablestoosharplytopreventcabledamage.

ThetablebelowliststhecorrectdevicesandSATAconnectors:

Device SATA connector

DOM SATA0

HDD1 SATA1

HDD2 SATA2

7. IftheSATAcablesdonothavealockingmechanism,usetie-wrapstosecurethecablesonthedisk(s)in

thefollowingway:



8. Ifthereareunusedcablesleft,bundlethemwithtie-wraps.

Default Chapter5
- Table of Contents5
