ADPRO iFT Series Hardware Installation Manual
27817_05 61
15 Retrieving the IP Address
TheXOclientdisplaystheXOdevice’sIPaddressinthetitlebar.However,ifyoucannotconnecttotheXO
device,youcanfindtheIPaddressasfollows:
1. Connectamonitor/screenandakeyboardtotheXOdevice.
2. Ifthemonitordisplaysthevideomatrix,pressCtrl+Alt+F1.TheXOwelcomescreenappears:
ADPRO XO 04.00.0007
Ip : 10.0.0.10
Subnet : 255.255.255.0
Gateway: 10.0.0.1
Port [HTTP]: 80
Port [CTRL]: 2000
Port [RTSP]: 554
TheXOwelcomescreendisplaysthefollowinginformation:

o
XOdevice(server)softwareversion

o
IPaddress,subnetmask,andgateway

o
HTTP,control,andRTSPportnumbers.
3. Toreturntothevideomatrixview,pressCtrl+Alt+F7.
