iFT Series Hardware Installation Manual ADPRO
42 27817_05
9 Net I/O Modules
TheEthernet(Net)I/OmodulesprovideextrainputsandoutputsforyourXOdevice.Youmountthemodulesona
DINrailandconnectthemtothelocalnetwork.Topowerthemodules:usePoE,aPoEinjector,oralocalpower
adapter(12VDC;800mA).
EachI/Omoduleoffers4inputsand4outputs,andLEDindicatorsandabuzzercontrolledbytheXOdevice.You
canextendeachbaseI/Omodulewith1to3submodules,toobtainupto16inputsandoutputs.
AsyoucanlinkyourXOdevicetoupto8I/Omodules(8basicmodules,eachwithupto3extensionmodules),
youcanobtainatotalof128extrainputsand128extraoutputs.
Caution!
Before plugging or unplugging any extension units, switch off the power to the base unit.
Pluggingorunpluggingextensionunitswithpoweron,mayresultinpermanent and irreparable
damage tothemainand/orextensionunits.
Fordetailedinstallationinstructions,seetheADPRO Ethernet I/O Datasheet (20148).
Baseunit: Extensionunit:
ToprogramtheIPaddressofanI/Omoduleandtoupdateitssoftware,youusetheNetFindertool.Youcanfind
thistoolontheCD/DVDdeliveredwiththesystem,oryoucandownloaditfromtheXtralisSupportwebsite
www.xtralissecurity.com.Forinstructions,seetheADPRO Ethernet I/O Datasheet (20148).
ToaddandconfiguretheNetI/Omodulesintheclientsoftware,seetheXO Client Software User Manual
(21796).
