ADPRO iFT Series Hardware Installation Manual

27817_05 29

5 Motherboards

5.1 Overview

TheiFTSeriesoperateswithaMiTACPH10LUmotherboard.

MiTACPH10LUmotherboard

5.2 BIOS Settings

ChooseMain >System Time tosetthesystemtime.

ChooseMain >System Date tosetthesystemdate.

ChooseChipset >PCH-IO Configuration >Front Panel Audio andselectLegacy Front Panel.

ChooseBoot >CSM parameters >Launch PXE OPROM policy andselectLegacy only.

ChooseSave & Exit >Exit and Reset andpressEnter.

Leaveallotherparameterstothedefaultsettings.

5.3 Connectors

Theimagebelowindicatestheavailablemotherboardconnectorsattherearofthedevice.

A PS/2:keyboardormouse G /dev/ttyU4(USB)

B DVI-I:monitor H /dev/ttyU3(USB)

C eth0:networkforXOdevice I DisplayPort:monitor

D eth1:networkforIPcameras J /dev/ttyU1(USB):modem

E Audiolinein K /dev/ttyU2(USB)

F Audiolineout 

Note

TheXOdevicedoesnotsupporttheUSB3portsonthePH10LUmotherboard.
