ADPRO iFT Series Hardware Installation Manual
27817_05 31
6 Connecting IP Cameras
AnXOdevicethatusesIPcamerasrequiresseparateIPnetworkconnectionsfor:
l ThenetworkforcommunicatingwiththeclientPC,CMS,NetI/Omodules,S3100panels…Theprimary
Ethernetconnector(eth0)onthemotherboardprovidesthephysicalinterfaceforthisnetwork.
l ThenetworkfortheIPcameras.ThesecondaryEthernetconnector(eth1)onthemotherboardprovidesthe
physicalinterfaceforthisnetwork.
Note
ItisnotpossibletohaveoverlappingIPaddressrangesineth0andeth1;thesemustbeseparate.
WithsoftwareversionXO4andabove,thesystemwillcheckandissueawarningiftheIPaddresses
ofeth0andeth1areinthesamerange.
