16.3 Retrieving Reports

TheXOdevicealsogeneratesreports.Youcanviewthesereportsviatheinternetbrowser.TypetheIPaddress

oftheXOdeviceintheaddressbarofthebrowserandadd/report.phptotheIPaddress.

Example:http://10.0.0.10/report.php

TheServerReportcontainsthefollowinginformation:

General Memoryusage

Time+zone

Processes

Uptime

Performance Vmstat

I/Ostat

PIDstat

MPstat

Network Interfaces–available

Interfaces–enabled

Routes

Listenports

Netstat–all

DEVstats

Sockstat

ARPcache
