Product Guide VESDA ECO Detector by Xtralis
58 Configuration 17898_05
Figure 45 Graph zoom using mouse
When a specific sensor is highlighted in the Detector Overviewzone of Xtralis
VSC’s main window, only the trend graph for that sensor will be displayed.
