50
30.0 Hz controlled HYDROVAR-pump, where the full speed
slave pump should stop, if “simple multicontroller” is set in the parameter Relay
configuration (see capter 13.8.1).
To leave the submenu press the Î key longer than 3 sec.!
13.9 Submenu Sensor
Submenu
Sensor
To enter this menu you have to press the Ð key, to
leave the menu, press the Î key longer than 3 sec.
13.9.1 Sensor – Adjust
SENSOR_ADJUST ?
Out of range
Zero adjustment of the transmitter
Depressurise the system and press keys Ð + Ï
simultaneously. After adjustment "adjusted" appears on the display. If “out of range” is
shown on the display, no adjustment is possible (e.g. when pressure is in the
system....)
Press
Î
on the controller to change to
13.9.2 SensorMax-Adjust
SENSORMAX-ADJUST
0,5 – 4,5 V
The analogue input (terminal X2/2) is prepared for a
transmitter signal of 0,5 – 4,5VDC.
When there is used a transmitter with another signal range, you can also choose an
input signal of 0,5 – 2,5VDC ( for example a 4-20mA-transmitter with an external load
resistor of 125 ohm/0,25W) with the buttons Ð + Ï.
To leave the submenu press the Î key longer than 3 sec.!
13.10 Submenu Test-Run
Submenu
Testrun
To enter this menu you have to press the Ð
key, to
leave the menu, press the Î key longer than 3 sec.
13.10.1 Start of manual test run
Start Test Run
Ï + Ð
By simultaneously pressing Ï + Ð a test run will be
released even if the test cycle is not set.
After starting this test run, the pump will speed up with the fasten ramp 1 to the in the
parameter 13.10.3 setted speed and then will ramp down with the fasten ramp 2.
