Xylem MJK Shuttle - Pump Control with Relays 1 and 2

22
EN 2.10 Shuttle Manual 1712
SW 838023
Display and keyboard
Pump control with relays 1 and 2
With these start and stop levels Shuttle
®
is now configured
for pumping out and reverts to normal read-out.
Select the time delay for relay 2 with the arrow keys.
Select the time delay for relay 1 with the arrow keys.
0,75 m
1,00 m
1.50 ft
3.75 ft
Start and stop level for pump no. 1 is set to
1,00 and 0,75 m respectively.
Start and stop level for pump no. 2 is set to 1,25
and 0,50 m respectively.
