EN 2.10 Shuttle Manual 1712
Appendix
Chemical Resistant Version
Shuttle
®
Ultrasonic Sensor Type 200660
Measuring range 10 m (liquids), 5 m (solids)
Frequency 50 KHz
Spread 6 °
Dead band 35 cm
Sensitivity See figure below
Temperature - 20 to + 60 °C
Materials PP, PVDF
Cable Shielded, insuated with oil resistant PVC,
length 12 m
(Max. 100 m with 690010 cable)
Enclosure IP 68, water-proof, withstands sub-
merging, max. 1 bar
CE approvals EN 50081-1, EN 50082-1
