61
SW 838023
EN 2.10 Shuttle Manual 1712
Appendix
Fixed mA signal
Enter the access code (see page 58) and press 'C'.
This menu is used to make Shuttle
®
give out a constant 12
mA signal independent of the actual level readout.
The function can be useful during fault finding on external
equipment.
Note:
The output signal is constant 12 mA as long as
this display is shown:
Shuttle
®
is ready for a new selection of a password protect-
ed menu after pressing 'Enter'.
(Re-entering the access code is not necessary if a menu
selection is made within 5 minutes.)
Press 'Escape' if no further password protected menu
selections are needed …
... or confirm with 'Enter' that the changes should be saved,
whereupon Shuttle
®
revert to normal read-out, and the next
password protected menu can be selected.
(Press 'Escape' if the changes should not be saved.)
