Xylem MJK Shuttle - System Alarm on Relay 1

24
EN 2.10 Shuttle Manual 1712
SW 838023
Display and keyboard
System alarm on relay 1
Shuttle
®
reverts to normal read-out.
Select the time delay.
Select relay mode.
('n.c' = normally closed,
'n.o' = normally open).
Note:
If 'n.c' is selected, Shuttle
®
will also give alarm in case of power failure.
In this menu the time delay is set for the activation of relay 1 when a system error occurs
together with the reset position of the relay (normally open / normally closed):
