31
SW 838023
EN 2.10 Shuttle Manual 1712
User and factory settings
Possible settings
Learning function: On / Off
Measuring unit: m / in / ft / mm / cm
Sensor / zero point distance: ± 60 m
Level read-out setting: ➀ ± 60 m
mA output: ➀ ± 14,64 m
➁ ± 15 m
Start level: From (zero point + distance to sensor) to (max. range - zero point)
Stop level: From (zero point + distance to sensor) to (max. range - zero point)
Relay delay: 0 to 300 sec.
NO/NC: NO / NC
Bar graph read-out: Off / mA output / level read-out
Active
0,1 to max. range
measuring range:
Response time:
0,1 to 300 mm/s
Measuring method 1 (Fluid) / 2 (Sludge and granulate)
mA signal at
Freeze / Fixed signal. (Fixed signal can be set from 3,5 to 20,5 mA)
system error:
Calibration of level readout: - 30 til 0,29 m
➀
➁
