Xylem wtw Multi 3410 - ORP Voltage; General Information; Measuring the ORP

Operation Multi 3410
59
ba75863y18 01/2015
4.7 ORP voltage
4.7.1 General information
You can measure the following parameters:
 ORP [mV]
Note
The sensor connection and the USB-B (device) interface are galvani-
cally isolated. This enables interference-free measurements in
grounded measuring media.
Preparatory activities Perform the following preparatory activities when you want to measure:
4.7.2 Measuring the ORP
Note
IDS ORP sensors are not calibrated. However, you can check IDS
ORP sensors using a test solution.
1 Connect the IDS ORP sensor to the meter.
The ORP measuring window is displayed.
2 Check the meter with the IDS ORP sensor.
1 Perform the preparatory activities according to section 4.6.1.
2 Immerse the IDS ORP sensor in the test sample.
3 Select the mV display with <M>.
15.03.2014 08:00
Info
