Yamaha DM2000 Service Manual

DM2000
6
STUDIO MONITOR OUT
Monitor select
CONTROL ROOM, STEREO, AUX 11, AUX 12
DA converter
24-bit linear, 128-times oversampling
Level control
Analog rotary potentiometer
2TR OUT DIGITAL 1–3
Dither
On/off
Word length 16, 20, 24-bit
Output patch
STEREO, BUS1–8, AUX 1–12, MATRIX 1L–4R, DIRECT OUT 1–96,
INSERT OUT, CONTROL ROOM
SRC
On/off (1:3 and 3:1 maximum input to output sample rate ratio)
Option Output (SLOT 1–6)
Available card
Optional digital interface card (MY8, MY4 series)
Output patch
SURROUND MONITOR, STEREO, BUS1–8, AUX1–12, MATRIX 1L–4R,
DIRECT OUT 1–96, INSERT OUT (CH1–96, BUS1–8, AUX1–12,
MATRIX 1L–4R, STEREO)
Dither
On/off
Word length 16/20/24-bit
Memory card slot
SmartMedia
STEREO
Comp-type
*4
On/off
Pre EQ/pre fader/post fader
Attenuator
–96.0 to +12.0 dB (0.1 dB step)
EQ
4-band PEQ
*5
On/off
On/off
Fader
100 mm motorized
Balance
127 positions (Left=1–63, Center, Right=1–63)
Delay
0–43400 samples
Matrix send
Pre fader/post fader
Level (–∞, –96 dB to +10 dB)
Pan: 127 positions (Left=1–63, Center, Right=1–63)
Metering
Displayed on LCD
Peak hold on/off
BUS1–8
Comp-type
*4
On/off
Pre EQ/pre fader/post fader
Attenuator
–96.0 to +12.0 dB (0.1 dB step)
EQ
4-band PEQ
*5
On/off
On/off
—
Fader
100 mm motorized
Delay
0–43400 samples
Matrix send
Pre fader/post fader
Level (–∞, –96 dB to +10 dB)
Pan: 127 positions (Left=1–63, Center, Right=1–63)
Bus to stereo
Level (–∞, –130 dB to 0 dB)
On/off
Pan: 127 positions (Left=1–63, Center, Right=1–63)
Metering
Displayed on LCD
Peak hold on/off

Yamaha DM2000 Specifications

General

Type	Digital Mixing Console
Channels	96
Sampling Rate	44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Bit Depth	24-bit
Aux Sends	12
Matrix	8 x 8
EQ Bands	4-band parametric
Word Clock	Yes
Effects	Internal Effects Processors
Digital I/O	AES/EBU, ADAT
Display	LCD
