Yamaha DM2000 Service Manual

DM2000
7
AUX1–12
Comp-type
*4
On/off
Pre EQ/pre fader/post fader
Attenuator
–96.0 to +12.0 dB (0.1 dB step)
EQ
4-band PEQ
*5
On/off
On/off
—
Fader
100 mm motorized
Delay
0–43400 samples
Matrix send
Pre fader/post fader
Level (–∞,–96 dB to +10 dB)
Pan: 127 positions (Left=1–63, Center, Right=1–63)
Metering
Displayed on LCD
Peak hold on/off
MATRIX 1L–4R
Comp-type
*4
On/off
Pre EQ/pre fader/post fader
Attenuator
–96.0 to +12.0 dB (0.1 dB step)
EQ
4-band PEQ
*5
On/off
On/off
—
Fader
100 mm motorized
Balance
127 positions (Left=1–63, Center, Right=1–63)
Delay
0–43400 samples
Metering
Displayed on LCD
Peak hold on/off
SURROUND MONITOR
Mute
On/off
Solo
On/off
Source
BUS1–8, SLOT 1–6
Monitor to C-R
On/off
Oscillator
Pink noise/500–2 kHz/1 kHz
Monitor matrix
5.1→5.1, 5.1→3-1, 5.1→ST, 3.1→3.1, 3.1→ST
Bass
management
5 presets
Monitor
alignment
ATT (–12.0 dB to 12 dB 0.1 dB step), Delay (0–30.0 msec 0.01 msec
step)
INTERNAL EFFECTS
(EFFECT 1–8)
Bypass
On/off
In/out
8-in, 8-out (EFFECT1–2): depends on effects type
2-in, 2-out (EFFECT3–8): depends on effects type
Effect-in from
AUX1–12/INSERT OUT/effect-out
Effect-out to
Input patch/effect-in
GRAPHIC EQUALIZERS
(GEQ 1–6)
On/off
—
Band number
31
Limit
±15 dB, ±12 dB, ±6 dB, –24 dB
Insert position
BUS1–8/AUX1–12/STEREO L, R/MATRIX 1L–4R
Japan
100 V, 50/60 Hz 230 W WITH OPTION 230 W WITHOUT OPTION 165 W
Power Requirements U.S./Canada
120 V, 60 Hz 300 W
Other 220–240 V, 50/60 Hz 300 W
Dimensions (H x D x W) 257 x 821 x 906 mm (10.1" x 32.3" x 35.7")
Net weight
43 kg (94.8 lbs)
Operating free-air temperature range
10–35°C (50–95°F)
Storage temperature range
–20 to 60 °C (–4 to 140°F)

Yamaha DM2000 Specifications

General

Type	Digital Mixing Console
Channels	96
Sampling Rate	44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Bit Depth	24-bit
Aux Sends	12
Matrix	8 x 8
EQ Bands	4-band parametric
Word Clock	Yes
Effects	Internal Effects Processors
Digital I/O	AES/EBU, ADAT
Display	LCD
