26
Preparations
Speaker Settings
The DSP-AX1 has seven SPEAKER SET items in the SET MENU that you must set according to the number of speakers in your
configuration and their size. The following table summarizes these SPEAKER SET items, and shows the initial settings as well as other
possible settings.
If the initial settings are not appropriate for your speaker configuration, change the settings in the SET MENU (see page 37).
Summary of SPEAKER SET items 1A through 1G
Item
Selects the Center channel output mode according to the size of the Center speaker.
The possible settings are LRG (large), SML (small) and NONE.
Selects the Main channel output mode according to the size of the Main speakers.
The possible settings are LARGE and SMALL.
Selects the Rear channel output mode according to the size of the Rear speakers.
The possible settings are LRG (large), SML (small) and NONE.
Selects the Rear center channel output according to the size of the Rear Center speaker.
The possible settings are LRG (large), SML (small) and NONE.
Selects a speaker for the LFE/Bass signal output.
The possible settings are SW (subwoofer), MAIN, and BOTH.
Selects the Front Effect signal output mode for the Front Effect signals.
The possible settings are YES and NONE.
Selects the output level for the Main channel signal.
The possible settings are Normal and –10 dB.
Initial SettingDescription
1A. CENTER SP
1B. MAIN SP
1C. REAR L/R SP
1D. REAR CT SP
1E. LFE/BASS OUT
1F. FRNT EFCT SP
1G. MAIN LEVEL
LRG
LARGE
LRG
LRG
BOTH
YES
Normal
To Next Page
