Specifications
Audio Section
Minimum RMS Output Power per Channel
MAIN L/R, CENTER, REAR L/R/C
(20 Hz to 20 kHz, 0.015% THD, 8 ohms) ------------ 110 W
FRONT L/R (1 kHz, 0.05% THD, 8 ohms) ------------ 35 W
Maximum Power [for General and China models]
MAIN L/R, CENTER, REAR L/R/C
(1 kHz, 10% THD, 8 ohms) ---------------------------- 150 W
FRONT L/R (1 kHz, 10 %THD, 8 ohms) -------------- 45 W
Dynamic Power (IHF) [for General and China models]
MAIN L/R (8/6/4/2 ohms) -------------- 150/180/240/340 W
Dynamic Headroom [for General and China models]
MAIN L/R (8 ohms) --------------------------------------1.3 dB
DIN Standard Output Power per Channel
[for Europe and U.K. models]
MAIN L/R (1 kHz, 0.7% THD, 4 ohms) ------------- 180 W
IEC Power [for Europe and U.K. models]
MAIN L/R (1 kHz, 0.015 % THD, 8 ohms)---------- 120 W
Power Band Width
MAIN L/R (55 W, 0.04% THD, 8 ohms)
---------------------------------------------------10 Hz to 50 kHz
Damping Factor
MAIN L/R (20 Hz to 20 kHz, 8 ohms) --------- 200 or more
Input Sensitivity/Impedance (110 W/8 ohms)
CD, etc. ------------------------------------- 150 mV/47 k-ohms
PHONO MM ------------------------------- 2.5 mV/47 k-ohms
MAIN IN -----------------------------------------1 V/47 k-ohms
Output Level/Impedance
REC OUT ----------------------------------- 150 mV/600 ohms
MAIN OUT ------------------------------------- 1 V/1.2 k-ohms
SUBWOOFER [SPLIT L/R] ----------------- 2 V/1.2 k-ohms
[MONO] ------------------ 4 V/1.2 k-ohms
PHONES Output ------------------------------------ 150 mV/100 ohms
Frequency Response (10 Hz to 100 kHz)
CD, etc. to MAIN L/R SP. OUT ------------------------ –3 dB
Total Harmonic Distortion (20 Hz to 20 kHz)
CD, etc. to MAIN OUT (1 V) ----------------- 0.005% or less
MAIN IN to SP OUT (55 W/8 ohms) -------- 0.005% or less
Signal to Noise Ratio (IHF-A network)
(Input shorted, EFFECT off) ------------------ 96 dB or more
Residual Noise (IHF-A network)
MAIN L/R SP. OUT --------------------------- 150 µV or less
Channel Separation (Vol –30 dB, 5.1 k-ohms terminated)
1 kHz/10 kHz ---------------------------- 70 dB/60 dB or more
Tone Control (MAIN L/R)
Bass Boost/Cut ---------------------------------±10 dB (50 Hz)
Treble Boost/Cut ----------------------------- ±10 dB (20 kHz)
Bass Extension ---------------------------------- +6 dB (60 Hz)
Video Section
Video Signal Type
[Europe and U.K. models] --------------------------------- PAL
[General and China models] ---------------------- NTSC/PAL
Composite Video Signal Level ----------------------- 1 Vp-p/75 ohms
S-Video Signal Level
Y------------------------------------------------- 1 Vp-p/75 ohms
C -------------------------------------------- 0.286 Vp-p/75 ohms
Component Video Signal Level
Y------------------------------------------------- 1 Vp-p/75 ohms
P
B/CB, PR/CR --------------------------------- 0.7 Vp-p/75 ohms
Maximum Input Level ------------------------------------------ 1.5 Vp-p
Signal to Noise Ratio ------------------------------------ 50 dB or more
Frequency Response
(MONITOR OUT) ------------------- 5 Hz to 10 MHz, –3 dB
General
Power Supply
[Europe and U.K. models] ----------------- AC 230 V, 50 Hz
[Other models] -----------AC 110/120/220/240 V, 50/60 Hz
Power Consumption----------------------------------------------- 550 W
AC Outlets (Total 100 W maximum)
[U.K. model]-------------------------------------- 1 (Switched)
[Other models] ----------------------------------- 3 (Switched)
Dimensions (W x H x D) -------------------------471 x 211 x 473 mm
(18-1/2” x 8-1/4” x 18-5/8”)
Weight ----------------------------------------------- 28 kg (61 lbs 11oz)
Accessories ----------------------------------------------- Remote control
Alkaline batteries
Quick reference guide
*Specifications are subject to change without notice.
