71
English
CINEMA-DSP Sound Field Program
According to the input signal format, the DSP-AX1 automatically chooses the appropriate decoder and DSP sound field pattern.
Program
Group
7
8
9
10
11
12
CONCERT
VIDEO 1
CONCERT
VIDEO 2
TV
THEATER
MOVIE
THEATER 1
MOVIE
THEATER 2
PRO LOGIC
DOLBY
DIGITAL
DTS
DIGITAL SUR
Pop/Rock
DJ
Classical/Opera
Pavilion
Mono Movie
Variety/Sports
70 mm Spectacle
70 mm Sci-Fi
70 mm Adventure
70 mm General
Normal
Enhanced
Input
Stereo
(2ch)
DOLBY DIGITAL
(5.1ch)
DTS Spectacle
DTS Sci-Fi
DTS Adventure
DTS General
Normal
Enhanced
DTS
(5.1ch)
DOLBY DIGITAL
(6.1ch)*
DTS ES
(6.1ch)*
Table of Program Names for Each Input Format
* The Matrix decoder is ON.
Program Groups 7~9
These are sound field programs for the audio-video sources.
Program Groups 10~12
Ideal for reproducing a movie program which is encoded with Dolby Surround, Dolby Digital, or DTS. When the newest movie
program encoded with Dolby Digital Surround EX or DTS ES is input, you can enjoy the full 6.1 channel reproduction using the
internal Matrix decoder.
PRO LOGIC functions when the input signal is analog or PCM audio, or encoded with Dolby Digital in two channels.
DOLBY DIGITAL functions when the input signal is encoded with Dolby Digital in more than two channels.
DTS DIGITAL SUR functions when the input signal is encoded with DTS.
Note:
No sound wil be output from the Main speakers when a monaural source is played with sound field Program Groups 7~12.
Spectacle ES
Sci-Fi ES
Adventure ES
General ES
ES
Enhanced ES
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
Spectacle 6.1
Sci-Fi 6.1
Adventure 6.1
General 6.1
Matrix 6.1
Enhanced 6.1
– – – – – – – –
– – – – – – – –
– – – – – – – –
– – – – – – – –
DGTL Spectacle
DGTL Sci-Fi
DGTL Adventure
DGTL General
Normal
Enhanced
