42
Advanced
Operation
SET MENU Items
Use this feature to adjust the Subwoofer volume so it matches the volume of the other speakers in your configuration. Change the setting
using the remote control while sitting in the main listening position.
1
1
Press + or – (or SET MENU + or –) to set TEST TONE to “ON”, and adjust the volume using VOLUME + (or
VOLUME) so you can hear the tone.
2
2
Press
%
(or NEXT) repeatedly to go to OUTPUT and press + or – (or SET MENU + or –) to select the speaker you
want to compare with the Subwoofer.
• If “SUBWOOFER” is selected, test tones above 90 Hz will not be output from the Subwoofer. The test tone will not necessarily
be output from the selected speakers. The output mode of the test tone depends on the settings of the 1. SPEAKER SET items in
the SET MENU.
3
3
Press
%
(or NEXT) repeatedly to go to FREQ. and press + or – (or SET MENU + or –) to select the frequency you
want to use.
4
4
Adjust the Subwoofer volume using the controls on the Subwoofer so it matches the volume of the speaker you are
comparing it to.
Notes:
• Do not turn up the VOLUME too high.
• If no test tone is heard, turn off the power and make sure all the necessary hookups are correct.
■ About the Test Tone
The test tone is produced by the tone generator.
The tone generator produces a narrow band noise centered at a specified
frequency by the band pass filter.
You can change the center frequency from 35 Hz through 250 Hz in one-sixth
octave steps.
You can use the test tone not only for adjusting the subwoofer level, but also for
checking the low frequency characteristics of your listening room. Low frequency
sounds are especially affected by the listener’s position, speaker placement,
subwoofer polarity and other conditions.
Digital Generator
(Wide Band Noise Produced)
Band Pass Filter
2. LOW FREQ. TEST
Center freq. 35 Hz~250 Hz
NOISE
FREQ.
To Next Page
