P.C.B. INPUT
Schm
Ref. PARTNO. Description Market
NewParts
*
Schm
Ref. PARTNO. Description Market
NewParts
*
* V7209300 P.C.B. INPUT RT
* V7209400 P.C.B. INPUT BG
CB301 Vi878100 CN.BS.PIN 3P
CB302 VP082900 CN.BS.PIN 25P
* CB303 VQ048600 CN 37PTE
CB304 VQ047800 CN.BS.PIN 27P
CB306 VP573800 CN.BS.PIN 18P
CB307 VM688900 CN.BS.PIN 10P
CB308 VK025300 CN.BS.PIN 9P
CB309 VQ963500 CN.BS.PIN 14P
CB310 VQ962800 CN.BS.PIN 7P
CB311 VQ961000 CN.BS.PIN 7P
CB312 VQ961700 CN.BS.PIN 14P
CB501 Vi878700 CN.BS.PIN 9P
CB581 Vi878100 CN.BS.PIN 3P
C301 UA652100 C.MYLAR 100pF50V BG
C302 UA652220 C.MYLAR 220pF50V
C303 UA652100 C.MYLAR 100pF50V BG
C304 UA652220 C.MYLAR 220pF50V
C305 US064100 C.CE.M.CHP 0.01uF50V
C306 UT652100 C.PP 100pF100V
C307 UT652100 C.PP 100pF100V
C308 UA652100 C.MYLAR 100pF50V
C309 UA652100 C.MYLAR 100pF50V
C310 FG651470 C.CE 47pF50V
C311 FG651470 C.CE 47pF50V
C312 UA652100 C.MYLAR 100pF50V
C313 UA652100 C.MYLAR 100pF50V
C314 UA652100 C.MYLAR 100pF50V
C315 UA652100 C.MYLAR 100pF50V
C316 US062100 C.CE.M.CHP 100pF50V
C317 US062100 C.CE.M.CHP 100pF50V
C318 US061470 C.CE.M.CHP 47pF50V
C319 US061470 C.CE.M.CHP 47pF50V
C320 US062100 C.CE.M.CHP 100pF50V
C321 US062100 C.CE.M.CHP 100pF50V
C322 US061470 C.CE.M.CHP 47pF50V
C323 US061470 C.CE.M.CHP 47pF50V
C324 UA654100 C.MYLAR 0.01uF50V
C325 US064100 C.CE.M.CHP 0.01uF50V
C326 UR828220 C.EL 220uF10V
C327 UA653910 C.MYLAR 9100pF50V
C328 UA654330 C.MYLAR 0.033uF50V
C329 UA653910 C.MYLAR 9100pF50V
C330 UA654330 C.MYLAR 0.033uF50V
C331 UR828220 C.EL 220uF10V
C332 UR866220 C.EL 2.2uF50V
C333 VG288800 C.EL 47uF50V
C334 UA653100 C.MYLAR 1000pF50V
C335 UA653100 C.MYLAR 1000pF50V
C336 VG288800 C.EL 47uF50V
C337 UR866220 C.EL 2.2uF50V
C341 VD930900 C.CE.SMI 0.1uF25V
C342 VD930900 C.CE.SMI 0.1uF25V
C344 UU137100 C.EL 10uF16V
C345 VG288800 C.EL 47uF50V
C346 VG288800 C.EL 47uF50V
C347 UU137100 C.EL 10uF16V
C348 VD930900 C.CE.SMI 0.1uF25V
C349 VD930900 C.CE.SMI 0.1uF25V
C350 UU137100 C.EL 10uF16V
C351 UU137100 C.EL 10uF16V
C352 VD930900 C.CE.SMI 0.1uF25V
C353 VD930900 C.CE.SMI 0.1uF25V
C354 UR866220 C.EL 2.2uF50V
C359 UR866220 C.EL 2.2uF50V
C360 VG290600 C.EL 2.2uF50V
C365 UR866220 C.EL 2.2uF50V
C368 UA654270 C.MYLAR 0.027uF50V
C369 UU147100 C.EL 10uF25V
C370 UU147100 C.EL 10uF25V
C371 UA654270 C.MYLAR 0.027uF50V
C372 UR847100 C.EL 10uF25V
C375 UR847100 C.EL 10uF25V
C376 UU147100 C.EL 10uF25V
C379 UR847100 C.EL 10uF25V
C380 UA654270 C.MYLAR 0.027uF50V
C381 UT652470 C.PP 470pF100V
C382 VG288800 C.EL 47uF50V
C383 VG288800 C.EL 47uF50V
C384 UT652470 C.PP 470pF100V
C385 UA654270 C.MYLAR 0.027uF50V
C386 VD930900 C.CE.SMI 0.1uF25V
C387 VG288800 C.EL 47uF50V
C388 VD930900 C.CE.SMI 0.1uF25V
C389 VG288800 C.EL 47uF50V
C390 UU147100 C.EL 10uF25V
C391 V4578900 C.EL 47uF35V
C392 V4578900 C.EL 47uF35V
C393 UU147100 C.EL 10uF25V
C394 US135100 C.CE.CHP 0.1uF16V
C395 US135100 C.CE.CHP 0.1uF16V
C396 US135100 C.CE.CHP 0.1uF16V
C397 US135100 C.CE.CHP 0.1uF16V
C398 US135100 C.CE.CHP 0.1uF16V
C399 US135100 C.CE.CHP 0.1uF16V
C400 VG287500 C.EL 47uF50V
C401 US135100 C.CE.CHP 0.1uF16V
C402 US135100 C.CE.CHP 0.1uF16V
C403 US135100 C.CE.CHP 0.1uF16V
C414 UR837100 C.EL 10uF16V
C419 UR837100 C.EL 10uF16V
C420 VG287200 C.EL 10uF50V
C423 UR837100 C.EL 10uF16V
C424 VG287200 C.EL 10uF50V
C425 UR837100 C.EL 10uF16V
