Yamaha DSP-AX620 Service Manual

DSP-AX620
DSP-AX620
76
P.C.B. INPUT
Schm
Ref. PARTNO. Description Market
NewParts
*
Schm
Ref. PARTNO. Description Market
NewParts
*
C428 UU137100 C.EL 10uF16V
C429 UU137100 C.EL 10uF16V
C430 UR837100 C.EL 10uF16V
C431 UA652100 C.MYLAR 100pF50V
C432 UA652100 C.MYLAR 100pF50V
C433 UR837100 C.EL 10uF16V
C437 UA652100 C.MYLAR 100pF50V
C439 UR837100 C.EL 10uF16V
C443 UU137100 C.EL 10uF16V
C444 UU137100 C.EL 10uF16V
C446 VN011900 C.EL 100uF35V
C447 VN011900 C.EL 100uF35V
C449 VG287200 C.EL 10uF50V
C450 UR837100 C.EL 10uF16V
C473 UT652100 C.PP 100pF100V
C474 UT652100 C.PP 100pF100V
C475 VG287200 C.EL 10uF50V
C476 VG287200 C.EL 10uF50V
C477 VG287200 C.EL 10uF50V
C478 VG287500 C.EL 47uF50V
C479 VG287500 C.EL 47uF50V
C501 VG287800 C.EL 330uF16V
C502 VG287800 C.EL 330uF16V
C503 UR837220 C.EL 22uF16V
C504 UR837220 C.EL 22uF16V
C505 UR866100 C.EL 1uF50V
C506 UR865100 C.EL 0.1uF50V
C507 UR865100 C.EL 0.1uF50V
C508 UR865100 C.EL 0.1uF50V
C509 UR865100 C.EL 0.1uF50V
C510 UR866100 C.EL 1uF50V
C511 VQ645600 C.MYLAR 100pF50V
C512 VQ645600 C.MYLAR 100pF50V
C513 UR837470 C.EL 47uF16V
C514 UT652100 C.PP 100pF100V
C515 UR866220 C.EL 2.2uF50V
C516 UT652100 C.PP 100pF100V
C517 UR866220 C.EL 2.2uF50V
C518 UR837470 C.EL 47uF16V
C519 UR847100 C.EL 10uF25V
C520 UR847100 C.EL 10uF25V
C521 UA655120 C.MYLAR 0.12uF50V
C522 UA654330 C.MYLAR 0.033uF50V
C523 UA654330 C.MYLAR 0.033uF50V
C524 UA655120 C.MYLAR 0.12uF50V
C581 US064100 C.CE.M.CHP 0.01uF50V
C582 UA652100 C.MYLAR 100pF50V
C583 UA652100 C.MYLAR 100pF50V
* D302 VU172500 DIODE.ZENR UDZS9.1B
D303 VU172000 DIODE.ZENR UDZS5.6BTE‑175.6V
D304 VU172000 DIODE.ZENR UDZS5.6BTE‑175.6V
D305 VV220700 DIODE.SHOT RB501V‑40
D306 VV220700 DIODE.SHOT RB501V‑40
D307 VV220700 DIODE.SHOT RB501V‑40
D308 VV220700 DIODE.SHOT RB501V‑40
D309 VV220700 DIODE.SHOT RB501V‑40
D310 VV220700 DIODE.SHOT RB501V‑40
D311 VV220700 DIODE.SHOT RB501V‑40
D312 VV220700 DIODE.SHOT RB501V‑40
D313 VV220700 DIODE.SHOT RB501V‑40
D314 VV220700 DIODE.SHOT RB501V‑40
D315 VV220700 DIODE.SHOT RB501V‑40
D316 VV220700 DIODE.SHOT RB501V‑40
D317 VT332900 DIODE 1SS355
D318 VT332900 DIODE 1SS355
IC301 XP894A00 IC LC78211
IC302 XP896A00 IC LC78213
IC303 XP894A00 IC LC78211
IC304 XP896A00 IC LC78213
IC305 XW173A00 IC CS3310‑KS
IC306 XW173A00 IC CS3310‑KS
IC307 XW173A00 IC CS3310‑KS
IC311 XF291A00 IC uPC4570G2
IC313 XF291A00 IC uPC4570G2
IC314 XF291A00 IC uPC4570G2
IC315 XF291A00 IC uPC4570G2
IC316 XF291A00 IC uPC4570G2
IC317 XF291A00 IC uPC4570G2
IC319 XF291A00 IC uPC4570G2
IC320 XF291A00 IC uPC4570G2
IC501 XF291A00 IC uPC4570G2
IC502 XF291A00 IC uPC4570G2
* PJ301 V5478700 JACK.PIN RJ‑1073F‑09‑0351A
* PJ302 V7046800 JACK.PIN MSP‑246V1‑01NI
* PJ303 V7046800 JACK.PIN MSP‑246V1‑01NI
* PJ304 V7046700 JACK.PIN MSP‑244V1‑01NI
* PJ305 V7189700 JACK.PIN 1P
* PJ581 V6771300 JACK.PIN YKC21‑3503
Q301 VD303700 TR 2SC3326A,B
Q302 VD303700 TR 2SC3326A,B
Q303 VD303700 TR 2SC3326A,B
Q304 VD303700 TR 2SC3326A,B
Q305 VD303700 TR 2SC3326A,B
Q306 VD303700 TR 2SC3326A,B
Q308 VD303700 TR 2SC3326A,B
Q310 iA103700 TR.CHP 2SA1037Q,R,S
Q311 VP872700 TR 2SC4488S,T
Q312 iA103700 TR.CHP 2SA1037Q,R,S
Q313 VP872600 TR 2SA1708S,T
Q314 VD303700 TR 2SC3326A,B
Q315 VD303700 TR 2SC3326A,B
R350 HV755100 R.CAR.FP 100Ω1/4W
R355 HV755100 R.CAR.FP 100Ω1/4W
R366 VP940200 R.MTL.OXD 47Ω1W
R367 VP940200 R.MTL.OXD 47Ω1W
R401 VP940200 R.MTL.OXD 47Ω1W
