Yamaha DSP-AX620 Service Manual

DSP-AX620
DSP-AX620
78
P.C.B. OPERATION
Schm
Ref. PARTNO. Description Market
NewParts
*
Schm
Ref. PARTNO. Description Market
NewParts
*
C629 US062470 C.CE.M.CHP 470pF50V
C630 UR866100 C.EL 1uF50V
C631 US061240 C.CE.CHP 24pF50V
C632 US061240 C.CE.CHP 24pF50V
C633 US062220 C.CE.CHP 220pF50V
C634 UR847100 C.EL 10uF25V
C635 US062120 C.CE.CHP 120pF50V
C636 US135100 C.CE.CHP 0.1uF16V
C637 UR827470 C.EL 47uF10V
C638 US135100 C.CE.CHP 0.1uF16V
C639 US062100 C.CE.M.CHP 100pF50V
C640 VF467000 C.CE.TUBLR 1000pF50V
C681 US062100 C.CE.M.CHP 100pF50V
C682 US062100 C.CE.M.CHP 100pF50V
C683 US062100 C.CE.M.CHP 100pF50V
C686 UR827470 C.EL 47uF10V
C687 UR827470 C.EL 47uF10V
C688 US135100 C.CE.CHP 0.1uF16V
C689 UR827470 C.EL 47uF10V
C690 UR827470 C.EL 47uF10V
C691 US135100 C.CE.CHP 0.1uF16V
C692 UR827470 C.EL 47uF10V
C693 UR827470 C.EL 47uF10V
C694 US135220 C.CE.CHP 0.22uF16V
C711 US062100 C.CE.M.CHP 100pF50V
C712 US062100 C.CE.M.CHP 100pF50V
C713 US062100 C.CE.M.CHP 100pF50V
C714 US135100 C.CE.CHP 0.1uF16V
C715 UR847100 C.EL 10uF25V
C716 US135100 C.CE.CHP 0.1uF16V
C717 UR847100 C.EL 10uF25V
C732 US135100 C.CE.CHP 0.1uF16V
C733 US135220 C.CE.CHP 0.22uF16V
C734 US135100 C.CE.CHP 0.1uF16V
C735 US062100 C.CE.M.CHP 100pF50V
C736 US062100 C.CE.M.CHP 100pF50V
C737 US064100 C.CE.M.CHP 0.01uF50V RTBG
C738 US064100 C.CE.M.CHP 0.01uF50V RTBG
C739 US064100 C.CE.M.CHP 0.01uF50V RTBG
C740 US063100 C.CE.M.CHP 1000pF50V
C741 US064100 C.CE.M.CHP 0.01uF50V BG
C742 US064100 C.CE.M.CHP 0.01uF50V BG
C743 US135220 C.CE.CHP 0.22uF16V
D501 VT332900 DIODE 1SS355
D502 VV220700 DIODE.SHOT RB501V‑40
D503 VT332900 DIODE 1SS355
D504 VT332900 DIODE 1SS355
D505 VT332900 DIODE 1SS355
D506 VT332900 DIODE 1SS355
D507 VU171900 DIODE.ZENR UDZ5.1B5.1V
D508 VU171900 DIODE.ZENR UDZ5.1B5.1V
D509 VU172300 DIODE.ZENR UDZ7.5B7.5V
D510 VT332900 DIODE 1SS355
D511 VT332900 DIODE 1SS355
D512 VU172100 DIODE.ZENR UDZS6.2B6.2V RT
D512 VU172200 DIODE.ZENR UDZ6.8B6.8V BG
D581 VT332900 DIODE 1SS355
D582 VT332900 DIODE 1SS355
D583 VT332900 DIODE 1SS355
D584 VT332900 DIODE 1SS355
D585 VT332900 DIODE 1SS355
D586 VT332900 DIODE 1SS355
D587 VT332900 DIODE 1SS355
D588 VT332900 DIODE 1SS355
D589 VT332900 DIODE 1SS355
D590 VT332900 DIODE 1SS355
D731 VU172500 DIODE.ZENR UDZS9.1B
D732 VT332900 DIODE 1SS355
D733 VT332900 DIODE 1SS355
* G731 V6865600 PLATE.GND
* IC501 XZ619A00 IC uPD78421AGF
* IC502 XZ615A00 IC LC75725E
IC503 XJ757A00 IC NJM78L05A‑T3
IC581 XW939A00 IC TK15420MVIDEOAMP
* IC582 XY549A00 IC TC74HC4051AFEL
* IC583 XY549A00 IC TC74HC4051AFEL
IC584 iR405300 IC TC74HC4053AP
IC585 iG142200 IC TC74HCU04AP
* IC586 XZ736A00 IC TC74HC164AF‑EL
IC587 XZ060A00 IC LC74781‑9798
IC588 XY443A00 IC LA71096CH
IC681 XW911A00 IC LA7108MVIDEOAMP
* IC682 XY549A00 IC TC74HC4051AFEL
IC711 XZ177A00 IC LA7104MVIDEOAMP
IC712 iR405300 IC TC74HC4053AP
* JK581 V5268700 JACK.DIN JY‑5036
* JK582 V5268700 JACK.DIN JY‑5036
* JK583 V5268700 JACK.DIN JY‑5036
JK584 VQ960400 CN.DIN 1P
JK731 V2589500 CN 1P
JK732 V6268100 JACK.PHONE YKB21
L581 V3233700 COIL 1.5uH
L582 V6236000 COIL 4.7uH
L583 V2726100 COIL 33uH
L731 V2726500 COIL 68uH
* PJ581 V7190400 JACK.PIN 6P
* PJ681 V7189800 JACK.PIN 1P
* PJ682 V7190000 JACK.PIN 2P
* PJ683 V7190000 JACK.PIN 2P
* PJ684 V7190000 JACK.PIN 2P
* PJ711 V7122000 JACK.PIN 9P
* PJ731 V7190100 JACK.PIN 3P
PN501 V3750200 PIN L=70
PN711 V3750200 PIN L=70
Q501 VV900500 TR 2SD1991AQ,R,S
Q502 VV900500 TR 2SD1991AQ,R,S
