Yamaha DSP-AX620 Service Manual

DSP-AX620
DSP-AX620
79
P.C.B. OPERATION & DSP
Schm
Ref. PARTNO. Description Market
NewParts
*
Schm
Ref. PARTNO. Description Market
NewParts
*
Q503 VV900500 TR 2SD1991AQ,R,S
Q504 iA093320 TR 2SA933SQ,R
Q505 iA093320 TR 2SA933SQ,R
Q506 iA093320 TR 2SA933SQ,R
Q507 VV900500 TR 2SD1991AQ,R,S
Q508 VV900500 TR 2SD1991AQ,R,S
Q509 VV900500 TR 2SD1991AQ,R,S
Q510 VG722000 TR.DGT DTC144ES
Q511 iA093320 TR 2SA933SQ,R
Q581 iC174020 TR 2SC1740SR,S
Q582 iC287820 TR 2SC2878A,B
Q583 VD678700 TR.DGT DTC114ES
Q584 iC174020 TR 2SC1740SR,S
Q585 iC287820 TR 2SC2878A,B
Q586 iC053540 TR 2SC535A,B,C
Q587 iC174020 TR 2SC1740SR,S
Q588 iA1015I0 TR 2SA1015Y
Q589 iC224030 TR 2SC2240GR,BL
SW501 V6322700 SW.RT.ENC REB161(9X7)PVB
SW502 V4586200 SW.RT.ENC REB161PVB20F
SW702 VG392900 SW.TACT SKHVAA
SW703 VG392900 SW.TACT SKHVAA
SW704 VG392900 SW.TACT SKHVAA
SW751 VG392900 SW.TACT SKHVAA
SW752 VG392900 SW.TACT SKHVAA
SW753 VG392900 SW.TACT SKHVAA
SW754 VG392900 SW.TACT SKHVAA
SW771 VG392900 SW.TACT SKHVAA
U501 VU591000 L.DTCT GP1U271X
* V501 V6785800 FL.DSPLY 10‑BT‑236GNK
XL501 V4610100 RSNR.CE 10MHz
XL581 VV949800 RSNR.CRYS 14.31818MHz RT
XL581 VV949900 RSNR.CRYS 17.734475MHz BG
* V6880300 SHEET
V6007100 SPACER.FL 4.6/10/32
* V7209900 P.C.B. DSP
CB801 V6022800 CN.FBRLINK 1PGP1FA551TZ
CB802 V5478200 CN.PHOT.SN 1PGP1FA551RZ
CB803 V5478200 CN.PHOT.SN 1PGP1FA551RZ
CB804 V5478200 CN.PHOT.SN 1PGP1FA551RZ
CB807 VQ045600 CN.BS.PIN 27P
C801 US135100 C.CE.CHP 0.1uF16V
C802 US135100 C.CE.CHP 0.1uF16V
C803 US135100 C.CE.CHP 0.1uF16V
C804 US135100 C.CE.CHP 0.1uF16V
C806 US061220 C.CE.M.CHP 22pF50V
C807 US135100 C.CE.CHP 0.1uF16V
C808 UR847100 C.EL 10uF25V
C809 US135100 C.CE.CHP 0.1uF16V
C810 US135100 C.CE.CHP 0.1uF16V
C811 UR847220 C.EL 22uF25V
C812 US135100 C.CE.CHP 0.1uF16V
C813 US044220 C.CE.M.CHP 0.022uF25V
C814 US061330 C.CE.M.CHP 33pF50V
C815 US063100 C.CE.M.CHP 1000pF50V
C816 US062220 C.CE.CHP 220pF50V
C817 US061100 C.CE.M.CHP 10pF50V
C818 US063100 C.CE.M.CHP 1000pF50V
C819 US135100 C.CE.CHP 0.1uF16V
C820 UR819100 C.EL 1000uF6.3V
C821 UR819100 C.EL 1000uF6.3V
C822 US135100 C.CE.CHP 0.1uF16V
C823 US135100 C.CE.CHP 0.1uF16V
C824 US135100 C.CE.CHP 0.1uF16V
C825 US061100 C.CE.M.CHP 10pF50V
C826 US135100 C.CE.CHP 0.1uF16V
C827 US135100 C.CE.CHP 0.1uF16V
C828 US135100 C.CE.CHP 0.1uF16V
C829 US135100 C.CE.CHP 0.1uF16V
C830 UR819100 C.EL 1000uF6.3V
C831 UR818100 C.EL 100uF6.3V
C832 US135100 C.CE.CHP 0.1uF16V
C833 UR819100 C.EL 1000uF6.3V
C834 UR818100 C.EL 100uF6.3V
C835 US135100 C.CE.CHP 0.1uF16V
C836 US135100 C.CE.CHP 0.1uF16V
C837 US135100 C.CE.CHP 0.1uF16V
C838 US061330 C.CE.M.CHP 33pF50V
C839 US135100 C.CE.CHP 0.1uF16V
C840 UR819100 C.EL 1000uF6.3V
C841 US135100 C.CE.CHP 0.1uF16V
C842 UR819100 C.EL 1000uF6.3V
C843 US061330 C.CE.M.CHP 33pF50V
C844 US135100 C.CE.CHP 0.1uF16V
C845 US061470 C.CE.M.CHP 47pF50V
C846 US061470 C.CE.M.CHP 47pF50V
C847 US061470 C.CE.M.CHP 47pF50V
C848 US061470 C.CE.M.CHP 47pF50V
C849 US061470 C.CE.M.CHP 47pF50V
C850 US061470 C.CE.M.CHP 47pF50V
C851 US061470 C.CE.M.CHP 47pF50V
C852 US061470 C.CE.M.CHP 47pF50V
C853 US061470 C.CE.M.CHP 47pF50V
C854 US061470 C.CE.M.CHP 47pF50V
C855 UR818100 C.EL 100uF6.3V
C856 US135100 C.CE.CHP 0.1uF16V
C857 US135100 C.CE.CHP 0.1uF16V
C858 US063470 C.CE.CHP 4700pF50V
C859 US135100 C.CE.CHP 0.1uF16V
C860 US062470 C.CE.M.CHP 470pF50V
C861 UR818100 C.EL 100uF6.3V
C862 US063470 C.CE.CHP 4700pF50V
C863 US135100 C.CE.CHP 0.1uF16V
