CYLINDER HEAD COVERS, CYLINDER HEADS
3-31
1
2
3
4
5
6
7
8
9
10
ENGINE
Order Job/Parts to remove Q’ty Remarks
12 Carburetor breather hose 1 From carburetor
13 Cylinder head assembly #2 1
14 Gasket 1
15 Dowel pin 2
8 N・m (0.8 kgf・m, 5.9 lb・ft)
8 N・m (0.8 kgf・m, 5.9 lb・ft)
45 N・m (4.5 kgf・m, 33 lb・ft)
25 N・m (2.5 kgf・m, 18 lb・ft)
8 N・m (0.8 kgf・m, 5.9 lb・ft)
8 N・m (0.8 kgf・m, 5.9 lb・ft)
18 N・m (1.8 kgf・m, 13 lb・ft)
12
13
14
15
15
1st
2nd
