3-11
Outboard Rigging Guide - 2001 Switch Panels
Single Switch Panel Assembly
689-82570-18-00 (1998~: 9.9E ~ 30HP)
Single panel with push-to-choke ignition switch
and lanyard.
704-82570-06-00
C40T~C60, 9.9~250HP
Single panel with push-to-choke ignition switch,
lanyard, and warning horn.
REF
NO PART NUMBER DESCRIPTION QTY.
10 704-82570-06-00 Panel Switch Ass’y1
11 704-82510-06-00 • Main Switch Ass’y1
12 688-82575-01-00 • Engine Stop Switch Ass’y1
13 682-82556-00-00 • • Stopper 1
14 640-82581-00-00 • Stay, Cord Clamp 1
15 97303-05012-00 • Bolt 1
16 92903-05100-00 • Washer, Spring 1
17 95303-05700-00 • Nut 1
18 658-83383-11-00 • Buzzer 1
19 90149-05M05-00 Screw 4
20 95380-05600-00 Nut 4
21 92990-05100-00 Washer, Spring 4
22 92990-05600-00 Washer, Plate 4
To Next Page
