Yamaha F80 - Page 123

3-12
Outboard Rigging Guide - 2001 Switch Panels
22.5 mm
(1.01 in )
22.5 mm
(1.01 in )
110 mm (4.33 in)
51 mm (2.0 in)
8.5 mm (.33 in)
68 mm (2.67 in)
93 mm (3.66 in)
44.5 mm (1.75 in)
8.5 mm (.33 in) 2x 51 mm (2.02 in)
CUT OUT
THE SHADED
PORTION
SINGLE SWITCH PANEL ASSEMBLY
DRILL TEMPLATE (Actual Size)
