6A-5
Outboard Rigging Guide - 2001
Ref. No. Parts Name Qty. Remarks
1 Tiller Handle Ass’y 1
2 Neutral Switch 1
3 Neutral Switch Stay 1
4 Bolt 2 M6
5 Shift Control Lever 1
6 Spring Pin 1
7 Grommet 1
8 Steering Friction Ass’y 1
9 Bolt with Washer 2 M5
10 Extension, Wire Harness 1 10 pin - 12 pin
11 Wire Harness 1 A To buzzer
B To trim meter
C To tachometer
D To PTT switch
12 Connector ass’y 1
OPTION - TILLER HANDLE AND STEERING FRICTIO KIT
(For remote control model)
To Next Page
