6. Remove:
• Bolt 1
• Grommet retaining plate 2
• Bolt 3
• Hose locating plate 4
• Grommet 5
• Bolt 6
• Cable clamp 7
7. Disconnect:
• Overheat and oil warning lead coupler
1
• Trailer switch coupler 2
NEUTRAL SWITCH
1. Install:
• Neutral switch assembly 1
• Damper plate 2
• Neutral switch stay 3
• Bolt 4
NOTE:
Move the shift lever to the forward position
for operation.
2. Disconnect:
• Brown lead connector 1
3. Connect:
• Neutral switch lead connectors 1
Start in gear protection will not be
obtained without the neutral switch leads
connection.
E
WARNING
