Yamaha M7CL - General Specifications; Input;Output Characteristics

M7CL Owner’s Manual
293
Appendices
* Refer to the Yamaha professional audio website for information on supported I/O cards.
http://www.yamahaproaudio.com/
❏ Analog Input Characteristics
*1. Sensitivity is the lowest level that will produce an output of +4 dBu (1.23 V) or the nominal output level when the unit is set to maximum gain. (all fad-
ers and level controls are maximum position.)
*2. XLR-3-31 type connectors with latch are balanced. (1=GND, 2=HOT, 3=COLD)
* In these specifications, 0 dBu = 0.775 Vrms.
* All input AD converters are 24bit linear, 128 times oversampling.
* +48V DC (phantom power) is supplied to INPUT (1-48 or 1-32), ST IN 1L-4R, OMNI IN 1-8 and TALKBACK XLR type connectors via each individual
software controlled switches.
General Specifications
Sampling Frequency
Internal: 44.1 kHz, 48 kHz
External: 44.1kHz (-10%) to 48kHz (+6%) <M7CL-32/48>
44.1kHz (-2.5%) to 48kHz (+2.5%) <M7CL-48ES>
Signal Delay Less than 2.5 ms INPUT or OMNI IN to OMNI OUT (@Fs = 48 kHz)
Fader
M7CL-48/48ES: 100 mm motorized x62
M7CL-32: 100 mm motorized x46
Fader Resolution +10 to -138, - ∞ dB (1024 steps/100 mm)
Maximum Voltage Gain
M7CL-32/48: 86 dB INPUT 1–48 to OMNI OUT
M7CL-48ES: 86 dB OMNI IN 1–8 to OMNI OUT 1–8
Crosstalk (@1kHz)
M7CL-32/48: -80 dB Adjacent Input Channels (INPUT1–48, ST IN 1–4 [L, R], (GAIN:min) to
OMNI OUT 1–16)
M7CL-48ES: -80 dB Adjucent Input Channels (OMNI IN 1–8, (GAIN:min) to OMNI OUT 1–8)
Dimensions
M7CL-48/48ES: 1274 x 286 x 701 mm (W x H x D)
M7CL-32: 1060 x 286 x 701 mm (W x H x D)
Net Weight
M7CL-48: 50 kg
M7CL-32: 42 kg
M7CL-48ES: 46 kg
Power Requirements (wattage)
M7CL-48: 300 W
M7CL-32: 250 W
M7CL-48ES: 150 W
Power Requirements (voltage and hertz)
US/Canada: 120V 60Hz
Japan: 100V 50/60Hz
China: 110–240V 50/60Hz
Korea: 220V 60Hz
Other: 110–240V 50/60Hz
Operation free-air Temperature Range +10 °C to +35 °C
Storage Temperature Range -20 °C to +60 °C
Included Accessories
Owner’s Manual
Dust cover
Power cord
Cord clamp
Optional Accessories
Meter Bridge MBM7CL
mini YGDAI cards *
Gooseneck Lamp LA1L
Power Supply PW800W
Power Supply Link Cable PSL360
Input Terminals
GAIN
Actual Load
Impedance
For Use With
Nominal
Input Level
Connector
Sensitivity *1 Nominal
Max. Before
Clip
INPUT 1-48 <M7CL-48>
INPUT 1-32 <M7CL-32>
–62 dB
3 k Ω
50-600 Ω Mics
&
600 Ω Lines
–82 dBu
(61.6 µV)
–62 dBu
(0.616 mV)
–42 dBu
(6.16 mV)
XLR-3-31 type
(Balanced)
*2
+10 dB
–10 dBu
(245 mV)
+10 dBu
(2.45 V)
+30 dBu
(24.5 V)
ST IN 1-4 [L,R] <M7CL-32/48>
OMNI IN 1-8 <M7CL-48ES>
–62 dB
3 k Ω
50-600 Ω Mics
&
600 Ω Lines
–82dBu
(61.6 µV)
–62 dBu
(0.616 mV)
–42 dBu
(6.16 mV)
XLR-3-31 type
(Balanced)
*2
+10 dB
–10 dBu
(245 mV)
+10 dBu
(2.45 V)
+30 dBu
(24.5 V)
TALKBACK
–60 dB
3 k Ω
50-600 Ω Mics
&
600 Ω Lines
–70 dBu
(0.245 mV)
–60 dBu
(0.775 mV)
–40 dBu
(7.75 mV)
XLR-3-31 type
(Balanced)
*2
–16 dB
–26 dBu
(38.8 mV)
–16 dBu
(0.123 V)
+4 dBu
(1.23 V)
Input/output characteristics
General Specifications • Input/output characteristics
