Reference
Audio Signal Flow
Indicates the Audio signal connections. The connections will change depending on the status of the [USB
TO HOST] terminal and the general settings of the instrument.
MIDI Signal Flow
Indicates the MIDI signal connections. The connections will change depending on the general settings of
the instrument.
Quick Setup
Determines the Quick Setups.
Settings: Standalone, 1–3
The parameters for Quick Setups are as follows.
For details about parameters related to Audio Settings, see “Audio I/O” (page 190). For details about
parameters related to MIDI Settings, see “MIDI I/O” (page 191).
The default settings for Quick Setups are as follows.
Standalone
Use this setting when this instrument is to be used alone or as the master clock source for other
equipment.
MIDI Rec on DAW
Use this setting when recording this instrument’s performance (not including Arpeggio data) to the
DAW software.
Arp Rec on DAW
Use this setting when recording this instrument’s performance including Arpeggio data to the DAW
software.
Audio Settings
A/D Input Gain
L&R Gain
USB L&R Gain
USB 1–8 Gain
Direct Monitor Switch
MIDI Settings
MIDI In/Out
Local Control
Arp MIDI Out
MIDI Sync
Clock Out
Receive/Transmit Sequencer Control
Controller Reset
FS CC Number
Super Knob CC Number
Scene CC Number
Part Output Settings
Part 1–16 Output Select
A/D In Output Select
Digital In Output Select
Local Control Direct Monitor Output Select Arp MIDI Out
On On Main L&R Off
Local Control Direct Monitor Output Select Arp MIDI Out
Off On Main L&R Off
Local Control Direct Monitor Output Select Arp MIDI Out
Off On Main L&R On
