Destination
Determines the target parameter to be controlled. To add another Destination, touch “+” icon. For
information on setting examples for “Destination,” see below.
Settings: See the “Control List” in the Data List PDF document.
Destination Setting Examples
The following settings are some useful examples how to set the Destination.
Concerning *1 and *2, the following settings are necessary in addition to the above settings.
*1 “Ins A/B Type” = “Rotary Speaker” in the Effect display of Part Edit
*2 “Ins A/B Type” = “VCM Pedal Wah” in the Effect display of Part Edit
Source
Determines the desired Controller for controlling the parameter set in “Destination.”
Settings: PitchBend, Modwheel, AfterTouch, FootCtrl 1, FootCtrl 2, FootSwitch, Ribbon, Breath, AsgnKnob 1–8, AsgnSw 1,
AsgnSw 2, MS Lane 1–4, EnvFollow 1–16, EnvFollowAD, EnvFollowMst
Element SW (Element Switch)
Selects whether the controller will affect each individual Element (On) or not (Off). This is available only
when Element-related parameters are set in “Destination.”
Settings: Off, On
To control the volume: Part Param  Volume
To change the pitch: Part Param  Pitch
To change the speed of the Rotary Speaker: Ins A/B  InsA/B SpdCtrl
*1
To apply a Wah pedal effect: Ins A/B  InsA/B PdlCtrl
*2
