33
3
WARNING
● Thewheelchairmaytipoverifoperatedwhentheanti-tipdeviceisremovedorthesafety
wheels are not in the correct position. Do not operate the wheelchair when the safety
wheels are not in the correct position. Only have the safety wheels folded or facing
upwards when going over bumps with the assistant operations and other such situations.
● Continuingtousethewheelchairwithaprobleminthewheelchairbodyorthewheelsmay
cause sudden damage to the wheelchair while traveling, and may result in a rollover or fall.
(2) Rear tire
Check to ensure that there is tire
depth.
Check the surface of the tire to en-
sure that there are no cracks in it.
Check to ensure that there is air in
the tire. (Check by pressing the tire
with your nger.)
If not enough, pump up to 65 PSI
(450 kPa, 4.5kg/cm
2
) for
NAVIGO 24″ or 50 PSI (345 kPa,
2.5kg/cm
2
) for NAVIGO 16″.
Rear tire
Rear tire
If the safety wheels are facing upwards, be
sure to turn them so they face downwards.
Press in the lock pin and turn the safety
wheels.
Also, move the safety wheels as shown in the
gure to ensure that they are locked in position
and that their parts are not loose.
IncaseofNAVIGO16″
Lock pin
Safety wheel
Safety wheel facing upwards
Safety wheel facing downwards
NOTICE
● Pleasebeadvisedtheblacktiremayleavemarkonoororwall.
