5.2. Removing the Battery
Disconnect the battery from the wheelchair.
Store the battery with the protective cap on it.
<How to remove a nickel metal hydride (Ni-MH) battery>
<How to remove a lithium ion (Li-ion 00) battery>
Turn o󰀨 the power switch.
Turn o󰀨 the power switch.
Disconnect the battery by pulling
it straight outwards while press-
ing the release button.

Stand the grip upright.

Disconnect the battery by pull-
ing it straight outwards. (Do not
pull it out on an angle.)
Store the battery with the
protective cap on it.
Store the battery with the
protective cap on it.
Protective cap
Protective cap
WARNING
● Besuretostorethedisconnectedbatterywiththepro-
tectivecaponit.Exposedcontactscancauseshortcir-
cuitsandleadtoareorbatteryrupture.
Protective cap
