10. Wheelchair Transporting and Storing Instructions
Please refer to the Warnings in “1.5.16. Transporting and Storing the Wheelchair” on page 20 to 21.
10.1. Loading the Wheelchair in a Car
(1) Turn o the power of the wheelchair.
(2) Remove the battery.
Be sure to remove the battery from the wheelchair so that its power will
not turn on unexpectedly during transport.
Be sure to put the protective cap on the removed battery.
(3) Lock the wheels.
Set the left and right clutch levers to the power drive position so that the
wheels will not spin, and then apply the parking brakes.
(4) Remove any detachable parts.
Remove the foot-leg supports and any other parts that can be detached.
(5) Detach the drive units.
If necessary, detach the drive units from wheelchair frame.
Refer to “11. Wheelchair Disassembly and Adjustment” (pages 86 to
89).
(6) Fold the wheelchair.
If necessary, fold the wheelchair.
