7
7-8
Periodic maintenance and adjustment
To install the panel
1. Bolt
2. Quick fastener
1. Floorboard mat
1.Bolt
1. Spark plug cap
3. Remove the right floorboard mats
by pulling them up.
4. Remove the bolts, and then pull the
panel outward.
Place the panel in the original po-
sition, and then install the bolts.
Place the right floorboard mats in
their original position and push
them downward to secure them.
Install the bolt and the quick fas-
teners.
Install panel A.
1.
2.
3.
4.
Checking the spark plug
The spark plug is an important engine
component, which is easy to check.
Since heat and deposits will cause any
spark plug to slowly erode, the spark
plug should be removed and checked
in accordance with the periodic main-
tenance and lubrication chart. In addi-
tion, the condition of the spark plug
can reveal the condition of the engine.
To remove the spark plug
Place the vehicle on the center-
stand.
Remove panels A and B. (See page
7-7.)
Remove the spark plug cap.
1.
2.
3.
