7-34
Periodic maintenance and adjustment
10. Close the seat.
1. Taillight cover
2. Screw
1. Turn signal light bulb socket
1. Turn signal light bulb
Remove the turn signal light bulb
socket (together with the bulb) by
turning it counterclockwise.
Remove the burnt-out bulb by
pulling it out.
Insert a new bulb into the socket.
Install the socket (together with the
bulb) by turning it clockwise.
Install the taillight cover by install-
ing the screws.
Install the grab bar by installing the
bolts, and then tightening them to
the specified torque.
4.
5.
6.
7.
8.
9.
Tightening torque:
Grab bar bolt:
17 Nm (1.7 m·kgf, 12 ft·lbf)
