144 Chapter 12—Surround Pan
01V96 Version 2—Owner’s Manual
• ...................... The sound image moves between front and rear.
• ...................... The sound image moves from front left to rear right. With this pattern,
you can also fine-tune the trajectory by using the WIDTH, DEPTH,
OFFSET ( ), and OFFSET ( ) parameters.
• ...................... The sound image moves from front right to rear left. With this pattern,
you can also fine-tune the trajectory using the WIDTH, DEPTH,
OFFSET ( ), and OFFSET ( ) parameters.
• ...................... The sound image moves between left and right while tracing an arc.
With this pattern, you can also fine-tune the radius and shape of the
arc using the WIDTH, DEPTH, OFFSET ( ), and OFFSET ( )
parameters.
40 5636 40
36 36 36 12 8 8 44 16 20 16
36 36 36 12 8 8 44 16 20 16
40 48 44 44 20 32 28 56 32 24
