Surround Panning 145
01V96 Version 2—Owner’s Manual
Surround Pan
12
• ...................... The sound image moves between front and rear while tracing an arc.
With this pattern, you can also fine-tune the radius and shape of the
arc using the WIDTH, DEPTH, OFFSET ( ), and OFFSET ( )
parameters.
• ...................... The sound image moves while tracing a circle or oval. With this pat-
tern, you can also fine-tune the radius and shape of the circle or oval
using the WIDTH, DEPTH, OFFSET ( ), and OFFSET ( ) param-
eters.
4 If necessary, fine-tune the trajectory by editing the WIDTH, DEPTH, OFFSET
( ), and OFFSET ( ) parameter values.
5To move the sound image, move the cursor to anywhere outside the param-
eter boxes, then rotate the Parameter wheel.
The sound image of the selected channel moves along the selected trajectory pattern.
6To link the surround pan settings of two channels displayed on the page,
turn on the ST LINK button.
Use the PATTERN parameter box below the ST LINK button to specify how you want the
linked surround pan to move.
Tip: You can also adjust the front and rear or left and right movement, the trajectory pattern
and other parameters from an external MIDI device by assigning the surround parameters
to MIDI Control Changes (see page 220).
40 48 44 44 20 32 28 56 32 24
44 48 32 24 24 24 60 40 52 40
