10
PSR-E433 Owner’s Manual
Setting Up
Panel Controls and Terminals
Front Panel
q [MASTER VOLUME] control ................Page 14
w PITCH BEND wheel..............................Page 34
e [ ] (Standby/On) switch ....................Page 14
r LIVE CONTROL section
[ASSIGN] button ...............................Page 21
[A] and [B] knobs .............................Page 21
t [DEMO) button......................................Page 24
y [LESSON] button..................................Page 26
u [REC] button.........................................Page 28
i [METRONOME] button.........................Page 18
o TEMPO section
[TAP] button ......................................Page 42
[-] and [+] buttons .............................Page 42
!0 [PORTABLE GRAND] button ...............Page 16
!1 VOICE CONTROL section
[SPLIT] button...................................Page 17
[DUAL] button ...................................Page 16
[HARMONY] button ..........................Page 19
[ARPEGGIO] button..........................Page 20
!2 Playback Control buttons
• When the [PATTERN] lamp is turned on:
................................ Pages 23 and 42
• When the [SONG] lamp is turned on:
..............................................Page 25
• When the [STYLE] lamp is turned on:
.........................Pages 22, 40, and 41
GrandPno
001
001
q
e
r
t y u i
o !1
w
!0
!2 !3
@3
Front Panel
Display (page 15)
Setting Up

Yamaha PSR-E433 Specifications

General

Sound effects	Chorus, Reverberation
RMS rated power	5 W
Number of speakers	2
Metronome tempo range	11 - 280 bpm
Chorus effects quantity	4
Maximum polyphony (notes)	32
Music memory capacity (songs)	10
Reverberation effects quantity	9
Headphone outputs	1
USB connector type	USB Type-A
Keys quantity	61 keys
Product color	Black
Power consumption (max)	16 W

Weight and Dimensions

Depth	405 mm
Width	946 mm
Height	140 mm
Weight	6800 g
