Configuration screens
Reference Manual
TF Series
- 59 -
DELAY-REVERB (V1.1 and later)
One-input, two-output effect that has a delay and reverb connected in series.
EARLY REF (V1.1 and later)
One-input, two-output early reflection effect.
GATE REVERB, REVERSE GATE (V1.1 and later)
One-input, two-output early reflection with gate, and an early reflection with reverse gate.
CHORUS (V1.1 and later)
Two-input, two-output chorus effect.
FLANGE (V1.1 and later)
Two-input, two-output flanger effect.
Parameter Range Description
Delay 1.0ms - 2700.0ms Delay time.
Feedback Gain -99% - 99% Amount of feedback.
DLY BAL 0% - 100% Delay mix balance.
Reverb Time 0.3s - 20.0s Determines the length of the reverberation.
High Ratio 0.1 - 1.0 Ratio of high frequency reverberations to the Reverb Time.
Diffusion 0 - 10 Left and right spread of the reverberation.
Density 0% - 100% Density of the reverberation.
HPF Thru, 21.2Hz - 8.00kHz High-pass filter cutoff frequency.
LPF 50.0Hz - 16.0kHz, Thru Low-pass filter cutoff frequency.
REV BAL 0% - 100% Reverb mix balance.
Sync Off, On Parameter tempo sync.
Note
----, ~
Value used to calculate the delay time based on the tempo.
Parameter Range Description
Type
S-Hall, L-Hall, Random,
Reverse, Plate, Spring
Early reflection type.
Room Size 0.1 - 20.0 Room size; determines interval between early reflections.
Liveness 0 - 10 Decay of the early reflections (0: dead, 10: live).
Initial Delay 1.0ms - 500.0ms Delay before the early reflection.
Diffusion 0 - 10 Width of the reflections in the stereo field.
Density 0% - 100% Density of the reflections.
ER Number 1 - 19 Number of reflections.
Feedback Gain -99% - 99% Amount of feedback.
High Ratio 0.1 - 1.0 Amount of high-frequency feedback.
HPF Thru, 21.2Hz - 8.00kHz High-pass filter cutoff frequency.
LPF 50.0Hz - 16.0kHz, Thru Low-pass filter cutoff frequency.
Parameter Range Description
Type Type-A, Type-B Early reflection type.
Room Size 0.1 - 20.0 Room size; determines interval between early reflections.
Liveness 0 - 10 Decay of the early reflections.
Initial Delay 1.0ms - 500.0ms Delay before the early reflection.
Diffusion 0 - 10 Width of the reflections in the stereo field.
Density 0% - 100% Density of the reflections.
ER Number 1 - 19 Number of reflections.
Feedback Gain -99% - 99% Amount of feedback.
High Ratio 0.1 - 1.0 Amount of high-frequency feedback.
HPF Thru, 21.2Hz - 8.00kHz High-pass filter cutoff frequency.
LPF 50.0Hz - 16.0kHz, Thru Low-pass filter cutoff frequency.
Parameter Range Description
Frequency 0.05Hz - 10.00Hz Modulation speed
AM Depth 0% - 100% Depth of amplitude modulation.
PM Depth 0% - 100% Depth of pitch modulation.
MOD. Delay 1.0ms - 500.0ms Delay time of modulation.
Sync Off, On Parameter tempo sync.
Note
-
Value used to calculate the frequency based on the tempo.
Parameter Range Description
Frequency 0.05Hz - 10.00Hz Modulation speed
Depth 0% - 100% Depth of modulation.
MOD. Delay 1.0ms - 500.0ms Delay time of modulation.
Feedback Gain -99% - 99% Amount of feedback.
Sync Off, On Parameter tempo sync.
Note
-
Value used to calculate the frequency based on the tempo.
