CHAPTER2 PROFIBUS Unit
(16) Arrangement element number
read of currently specified C ................................................. Code 0210
The element number of the counter arrangement variable C currently specified is
read.
Command option
QWn+22
QWn+20 QWn+18 QWn+16
QWn+14 QWn+12
Command response
IWm+22
IWm+20 IWm+18 IWm+16
IWm+14 IWm+12
Element No.
(Example)
Transmission example 1:
The element number of the counter arrangement variable C is read.
QWn+22
QWn+20 QWn+18 QWn+16
QWn+14 QWn+12
QWn+10
QWn+8
0000
0000 0000
0000
0000 0000
0000 0210
Response example 1:
The element No. is 31.
IWm+22
IWm+20 IWm+18 IWm+16
IWm+14 IWm+12
IWm+10
IWm+8
0000
0000 0000
0000
0000 001F
0000 0200
