EDITING POINT DATA
7-3 Direct Teaching
7-3 Direct Teaching
1) On the initial screen, press
F1
(EDIT).
[EDIT-PNT-DTCH]
P0 X=0.00 [mm]
[ 0.00, 0.00]
1CHG 2DO 3Y 4next
[EDIT-PNT-DTCH]
Pn : n = _
(point No) 0→999
[EDIT-PNT-DTCH]
press EMG.button
[EDIT]
select menu
1PGM 2PNT 3UTL
[MENU]
select menu
1EDIT2OPRT3SYS 4MON
[EDIT-PNT]
select menu
1MDI 2TCH 3DTCH4DEL
2) Next, press
F2
(PNT).
3) Press
F3
(DTCH).
4) Following the message, press the emergency
stop button on the TPB.
5) The currently selected X-axis point data in the
execution program is displayed on the screen.
If you want to edit another point data, press the
STEP
UP
and
STEP
DOWN
keys to scroll the point data.
To directly select the point data, press
F1
(CHG).
6) Enter the point number you want to edit with
the number keys, and press
.
