117
CHAPTER2 PROFIBUS Unit
(18) Current counter variable D read ........................................... Code 0212
The value of the counter variable D is read.
Command option
QWn+22
QWn+20 QWn+18 QWn+16
QWn+14 QWn+12
Command response
IWm+22
IWm+20 IWm+18 IWm+16
IWm+14 IWm+12
Counter value
(Example)
Transmission example 1:
The value of the counter variable D is read.
QWn+22
QWn+20 QWn+18 QWn+16
QWn+14 QWn+12
QWn+10
QWn+8
0000
0000 0000
0000
0000 0000
0000 0212
Response example 1:
The element No. is 65535.
IWm+22
IWm+20 IWm+18 IWm+16
IWm+14 IWm+12
IWm+10
IWm+8
0000
0000 0000
0000
0000 FFFF
0000 0200
