84
CHAPTER2 PROFIBUS Unit
(18) Matrix definition ...................................................................... Code 0112
The matrix is defined.
Command option
QWn+22
QWn+20 QWn+18 QWn+16
QWn+14 QWn+12
Pallet number
Line number Array number
Command response
IWm+22
IWm+20 IWm+18 IWm+16
IWm+14 IWm+12
(Details)
Array number, Line number:
A value of 1 to 255 can be applied to each matrix.
Pallet number:
It is the inherent number of 0 to 31 for the matrix discrimination.
(Example)
Transmission example 1:
The matrix of 5×2 is defined at the 1st number.
QWn+22
QWn+20 QWn+18 QWn+16
QWn+14 QWn+12
QWn+10
QWn+8
0000
0000 0000
0001
0002 0005
0000 0112
Response example 1:
It is normally ended.
IWm+22
IWm+20 IWm+18 IWm+16
IWm+14 IWm+12
IWm+10
IWm+8
0000
0000 0000
0000
0000 0000
0000 0200
